WPL33
Find DealerFeatures
Advanced Lithium-Ion Battery
The WPL33 is equipped with an on-board Lithium-Ion battery. This 24V battery packs a big punch in a small package and is easy to recharge by removing the battery from its compartment. Lithium-Ion batteries have a lower overall cost of ownership compared to traditional lead acid batteries and are practically maintenance free.
Ease of Pallet Entry and Exit
The forks on the WPL33 are designed for use with a standard 48” pallet and can achieve a maximum elevation of over 7.75”. The tips of the forks are tapered, allowing for smooth entry and exit from the pallet.
Ergonomic Handle
On the handle of the WPL33, operators will find lift, lower, and travel functions, all within easy reach. The control handle can be operated with either hand, which includes a reverse switch, travel controls, horn, and battery discharge indicator. The tiller arm was designed with the operator in mind, with a low mounted arm which offers excellent operator comfort and reduces steering effort.
Advanced Electrical Componentry
The internal components are covered by water resistant connectors and a shrouded wiring harness, which provides continuous, reliable power to the components. The system includes a key switch, emergency power disconnect, and an on-board dock for easy exchange of the battery when charging.
Electromechanical Brakes
The electro mechanical brakes on the WPL33 provide immediate stopping power when the handle is upright or lowered beyond the operating range.
Serviceability
Reduce downtime and your overall cost of ownership with the WPL33. The removable covers and modular design of components provides for easy maintenance with simple hand tools. The two-piece drive wheel reduces the complexity of tire changes, which further decreases your service costs.
Applications
Tech Specs
| Load Capacity / Rated Load (lbs/kg) | Height Overhead Guard (in/mm) | Width (in/mm) | Right Angle Stack (in/mm) | Outside Turning Radius (in/mm) | Inside Turning Radius (in/mm) | Top Speed Loaded (kmp/mph) | Top Speed Unloaded (kmp/mph) | Power Unit - HP(KW) @rpm | |
|---|---|---|---|---|---|---|---|---|---|
| WPL33 | 3300 / 1497 | N/A / N/A | N/A | N/A | N/A / N/A | N/A / N/A | N/A / N/A | N/A / N/A | 24 Volt |
